Built in multi-level amplification chip, independent power supply to power the sensor for operation.
Multiple sensitivity inputs that can be switched.
High speed, transmission speed output, high dynamic response frequency.
Good long-term stability and anti-interference performance.
Built in multi-level amplification chip, independent power supply to power the sensor for operation.
Multiple sensitivity inputs that can be switched.
High speed, transmission speed output, high dynamic response frequency.
Good long-term stability and anti-interference performance.
| 外供电源 Power source |
5V DC | 输出 Output |
RS232, RS485 |
| 使用电压 Recommended Excitatio |
12VDC 24VDC | 最大使用电压 Maximum Excitation |
36V |
| 使用电压 Recommended Excitatio |
24VDC | 分辨率 Resolution |
1/50000 |
| 非线性(静态) Non-linearity (static) |
0.01% | 采 样速度 Sampling Rate |
(15~3840) HZ 可设 |
| 滞后 Hysteresis |
0.01% | 工作温度范围 Operating Temp Range |
-10 ℃ to 50 ℃、 湿度85%RH以下 |
| 重复性 Repeatability |
0.01% | 显示精度 Display Accuracy |
-99999-99999 |
| 功耗 Power |
约30W | 变送输出 Transmission Output |
RS232, RS485 |
| 动态性能 Dynamic performance |
200HZ→震动频率采样1920HZ 精度:5%以内 200HZ→震动频率采样3840HZ 精度:1.3%以内 |
||
| 主要应用 Applications |
可与各种电阻应变式、陶瓷压阻式、扩散硅压阻式传感器配套使用,实现对力、压力、重量、位移、扭矩、液位等物理量转换变送。可与我 公司研发生产的各种传感器配套使用,其信号可直接输入计算机或测控仪表。 voltage transmitter can work together with strain gages, ceramic piezoresistive sensors, and diffused silicon piezoresistive sensors which can realize the conversion and transmitting of physical quantity, such as force, pressure, weight, displacement, torque and liquid level. And the signal can be directly input in computers or other measurement and control instruments. |
||
